Standard parameters:
Belt width 800/1000/1200/1400 mm
Belt quality EP 400/3; 4+2
Support rollers Ø 89 mm
Support roller distance 1000 mm
Return rollers Ø 63 mm
Drive drum Ø 320 ~ 410 mm
Return pulley Ø 320 mm
Operating voltage 400/690 V - 50 Hz
Belt speed 0.8 m/sec or adapted to the conveying capacity
Support structure painted or galvanised.
Shaft-mounted geared motor with brake and backstop if required.
Reduced roller spacing in the material feed area.
Necessary protective devices at drive and deflection stations.
Pull cord switch in accordance with legal requirements.
Misalignment switch to ensure correct belt tracking.
Walkways on one or both sides in accordance with project development and legal requirements.
Slat scrapers adapted to the material requirements.
